針數Number of contacts345鎖緊方式Connector locking system螺...
|
針數 |
Number of contacts |
3 |
4 |
5 |
|
鎖緊方式 |
Connector locking system |
螺紋式/ screw |
||
|
連接方式 |
Termination |
螺紋，澆鑄電纜/ screw moulded on cable |
||
|
連接截面 |
Wire gauge |
螺紋 0.14-0.5mm 2 (AWG 26) /澆鑄電纜 0.25mm 2 (AWG 24) |
||
|
電纜直徑 |
Cable outlet |
螺紋 3.5-5mm /澆鑄電纜 4.5mm |
||
|
防護等級 |
Degree of protection |
IP67 |
||
|
機械壽命 |
Mechanical operation |
>100 插拔周期/ >100 mating cycles |
||
|
最高工作溫度 |
Upper temperature |
+ 80 ℃ |
||
|
最低工作溫度 |
Lower temperature |
- 20 ℃ |
||
|
額定電壓 |
Rated voltage |
60V |
30V |
|
|
額定沖擊電壓 |
Rated impulse voltage |
1000V |
800V |
|
|
污染等級 |
Pollution degree |
3 |
||
|
過電保護等級 |
Overvoltage categorie |
Ⅱ |
||
|
絕緣組別 |
Material group |
Ⅲ |
||
|
額定電流（40攝氏度） |
Rated current(40 ℃) |
4A |
||
|
觸點電阻 |
Contact resistance |
≤3mΩ |
||
|
觸點材料 |
Materila of contact |
CuZn( 黃銅/ brass) |
||
|
觸點電鍍材料 |
Contact plating |
Au( 金/ gold) |
||
|
插座材料 |
Materila of contact body |
PUR |
||
|
外殼材料 |
Materila of housing |
PUR |
||
