針數Number of contacts345鎖緊方式Connector locking system螺紋式/ screw連接方式Termination螺紋，澆鑄電纜/ screw moulded on cable連接截面Wire gauge螺紋 0.14-0.5mm 2 (AWG 26) /澆鑄電纜 0.25mm 2 (AWG 24)電纜直徑Cable outlet螺紋 3.5-5mm /澆鑄電纜 4.5mm防護等級Degree of protectionIP67機械壽命Mechanical op...
針數 | Number of contacts | 3 | 4 | 5 |
鎖緊方式 | Connector locking system | 螺紋式/ screw | ||
連接方式 | Termination | 螺紋，澆鑄電纜/ screw moulded on cable | ||
連接截面 | Wire gauge | 螺紋 0.14-0.5mm 2 (AWG 26) /澆鑄電纜 0.25mm 2 (AWG 24) | ||
電纜直徑 | Cable outlet | 螺紋 3.5-5mm /澆鑄電纜 4.5mm | ||
防護等級 | Degree of protection | IP67 | ||
機械壽命 | Mechanical operation | >100 插拔周期/ >100 mating cycles | ||
最高工作溫度 | Upper temperature | + 80 ℃ | ||
最低工作溫度 | Lower temperature | - 20 ℃ | ||
額定電壓 | Rated voltage | 60V | 30V | |
額定沖擊電壓 | Rated impulse voltage | 1000V | 800V | |
污染等級 | Pollution degree | 3 | ||
過電保護等級 | Overvoltage categorie | Ⅱ | ||
絕緣組別 | Material group | Ⅲ | ||
額定電流（40攝氏度） | Rated current(40 ℃) | 4A | ||
觸點電阻 | Contact resistance | ≤3mΩ | ||
觸點材料 | Materila of contact | CuZn( 黃銅/ brass) | ||
觸點電鍍材料 | Contact plating | Au( 金/ gold) | ||
插座材料 | Materila of contact body | PUR | ||
外殼材料 | Materila of housing | PUR | ||
